Does your beetleweight need more drive power?
Not happy with any of the options on the market?
Tired of trying to put your own shafts into a 2xxx motor to get all the torque???
Features:
- Custom wound 2006 brushless motor
- 2500kv – 2-4S voltage
- 24mm, 27:1 custom designed all metal planetary gearbox
- 6mm “D” extra long output shaft (cut to the length that you need to save weight)
- Custom billet 4130 final planet carrier and output shaft
- Output shaft c-clip has been changed to minimize the groove and provide the strongest product.
- 64.5g weight
- Custom square M3 facemount hole pattern (9mm apart, 22mm hole circle (~9x20mm rectangle))
- Pairs well with the Repeat AM32 Reversing ESC or Repeat Robotics AM32 Dual Brushless (good for a pair of motors).
-
Notes:
- These are brushless motors. If your receiver was being powered from a BEC in your brushed drive you'll need to add a BEC.
- These motors ship with bare leads, you'll need to solder them to the ESC or add your own connectors.
Cad Link:
https://grabcad.com/library/repeat-drive-pro-2006-1
