- These anodized 6061 aluminum Servo Mounts can hold your servos secure in a variety of positions.
- Mount right on the base with the lower holes, or spaced off the base using the higher mounting holes.
- Color May Vary between silver or red depending on stock.
Specifications:
- Sold in pairs (servo and screws not included)
- Material: Silver (used to be red) anodized 6061 Aluminum
- Width: 6.0mm (0.24in)
- Height: 20.0mm (0.79in)
- Length: 30.0mm (1.18in)
- Thickness: 3mm (0.12in)
- Three 4-40 holes along the short face spaced 5mm (0.2in) apart.
- Five 4-40 holes on the long face spaced 5mm (0.2in) apart.
- Weight: 2.0grams (0.07oz) each
